PR-E-PT100

£85.00 ex.VAT

PR-Series PLC Analogue Expansion Unit

  • RTD Input (PT100)

10 in stock (can be backordered)

Description

Expansion IO for ELC-18, ELC-22, ELC-26 and PR-18/24 Series – Analogue Input

  • Power Supply: 12 – 24 VDC
  • Digital:
    • Inputs – None
    • Outputs – None
  • Analogue:
    • Inputs – 3-channels (PT100)
    • Outputs – None

Additional information

Weight 0.2 kg
Dimensions 80 x 95 x 70 mm
Supply

Input Type

Inputs

Expansion IO Range

Model Supply DI DO AI AO Serial
PR-E-16AC-R 110~240VAC 8 x 240VAC (I1~I8) 4 x 3A (Q1~Q4)
4 x 10A (Q5~Q8)
0 0 0
PR-E-16DC-DA-R 12~24VDC 8 x 24 DC (I1~I8) 4 x 3A (Q1~Q4)
4 x 10A (Q5~Q8)
4 x 0-10V (I1~I4) 0 0
PR-E-16DC-DA-TN 12~24VDC 8 x 24 DC (I1~I8) 8 x 0.3A PNP (Q1~Q8) 4 x 0-10V (I1~I4) 0 0
PR-E-AI-I 12~24VDC 0 0 4 x 0-20mA 0 0
PR-E-PT100 12~24VDC 0 0 3 x PT100 (-50~200°C) 0 0
PR-E-AQ-VI 12~24VDC 0 0 0 2 x 0~10V or 0-20mA 0
PR-RS485 12~24VDC 0 0 0 0 1-channel

Downloads


PR-E-PT100 Datasheet
